Ashland Passive Multipoint Lock for Double Doors – 60mm Backset, 92mm PZ

Ashland Passive Multipoint Lock for Double Doors – 60mm Backset, 92mm PZ

SKU: 4991334

Sold out
$89.57 - $89.57
$89.57
$89.57 - $89.57
$89.57
  • PZ: 92mm (3-5/8")
  • Backset: 60mm (2-3/8")
  • Faceplate Length: 1040mm (40-15/16")
  • Faceplate Width: 20mm (13/16")
  • Passive lock for double door systems with astragal
  • Compatible with astragals from 1/2" (12.7mm) to 1" (25.4mm) thick
  • Can be rehanded for left or right door configurations
  • Sold individually
  • American Express
  • Apple Pay
  • Diners Club
  • Discover
  • Google Pay
  • Mastercard
  • PayPal
  • Shop Pay
  • Visa
Not sure this is the right part?
Before you order, if you'd like confidence this is the right part for your job, please fill out our multipoint lock identifier form or call us at (816) 221-6543 .
*We have a fully-staffed customer support team happy to help!

Ashland Passive Multipoint Lock – 60/92, 20mm Faceplate (4991334)

This Ashland passive multipoint lock is designed specifically for double door systems that utilize an astragal. The passive lock works in conjunction with an active multipoint lock on the primary door, allowing both doors to secure properly when closed.

The lock features a 60mm backset and 92mm PZ (handle center to cylinder center distance), with a 1040mm faceplate length suitable for standard door heights. The 20mm wide faceplate provides a secure fit in the door edge. This lock accommodates astragals ranging from 1/2 inch to 1 inch thick, making it versatile for various double door configurations.

Technical Information

  • PZ: 92mm (3-5/8 inches)
  • Backset: 60mm (2-3/8 inches)
  • Faceplate Length: 1040mm (40-15/16 inches)
  • Faceplate Width: 20mm (13/16 inches)
  • Astragal Compatibility: 1/2 inch to 1 inch thick
  • Original Manufacturer SKU: W5100STPAS8

Notes

  • This is a passive lock and requires an active multipoint lock on the primary door
  • Lock can be rehanded to accommodate left or right door configurations

Priced and sold each.

Fill out our MPL form or call us to ensure accurate purchasing and correct fit.

Frequently Asked Questions

What is a passive multipoint lock?

A passive lock is used on the inactive door of a double door system. It secures into the astragal or frame when closed, while the active door with the primary lock controls the locking mechanism.

Can this lock be rehanded?

Yes, this Ashland multipoint lock can be rehanded to work with either left or right door configurations.

What astragal thickness does this lock work with?

This passive lock is compatible with astragals ranging from 1/2 inch to 1 inch thick.
