Trilennium 3000 Series Multipoint Lock with Latch Bolts – 60mm Backset, Right Hand Inswing

Trilennium 3000 Series Multipoint Lock with Latch Bolts – 60mm Backset, Right Hand Inswing

SKU

$440.00 - $712.67
$440.00
$440.00 - $712.67
$440.00
  • Backset: 2-3/8" (60mm)
  • PZ: Not specified - contact us for details
  • Faceplate Width: 1" (25.4mm)
  • Faceplate Length: 55-1/2" (1410mm) with radius ends
  • Deadbolt Throw: 15/16" (23.8mm)
  • Top Latching Bolt: 23" (584.2mm)
  • Bottom Latching Bolt: 24-1/4" (616mm)
  • Standard Cross Bore: 2-1/8" (54mm) for Pinnacle, Eclipse & Grip hardware
  • Optional Cross Bore: 1-11/16" (42.9mm) for Europa, Horizon & Emtek hardware
  • Spindle Diameter: 1/4" (7mm)
  • Cylinder Type: American with flat tailpiece (not included)
  • Handing: Right Hand Inswing (reversible)
  • Faceplate Finishes: Available in 10 finishes
  • Panic release feature - pressing inside handle unlocks door
  • Handle moves down only to operate
Limited Inventory
Visa Mastercard American Express Discover
Estimated Delivery
Between December 13 and December 17
*Delivery dates are estimates and may vary based on availability and shipping method

Trilennium 3000 Multipoint Lock – 60mm Backset (499130012)

The Trilennium 3000 Series Multipoint Lock with Latch Bolts provides reliable security for residential entry doors. This lock features a 2-3/8 inch (60mm) backset and comes with both top and bottom latching bolts for comprehensive door security.

This multipoint lock offers flexibility with two cross bore options. The standard 2-1/8 inch cross bore accommodates Pinnacle, Eclipse, and Grip hardware, while the optional 1-11/16 inch cross bore works with Europa, Horizon, and Emtek hardware. The lock uses an American cylinder with a flat tailpiece, which is not included with the lock body.

Operation is straightforward: the handle moves down only to operate. To lock, use the key or thumb turn to extend the latch to deadbolt function. To unlock from outside, use the key; from inside, use the thumb turn or lever. The panic release feature allows the inside handle to unlock the door when pressed down, providing safe egress in emergencies.

Technical Information

  • Backset: 2-3/8 inches (60mm)
  • Faceplate Width: 1 inch (25.4mm)
  • Faceplate Length: 55-1/2 inches (1410mm)
  • Faceplate Style: Radius ends
  • Deadbolt Throw: 15/16 inch (23.8mm)
  • Top Latching Bolt Position: 23 inches (584.2mm)
  • Bottom Latching Bolt Position: 24-1/4 inches (616mm)
  • Spindle Diameter: 1/4 inch (7mm)
  • Standard Cross Bore: 2-1/8 inches (54mm)
  • Optional Cross Bore: 1-11/16 inches (42.9mm)
  • Cylinder Type: American with flat tailpiece (not included)
  • Handing: Right Hand Inswing (reversible)
  • Available Finishes: 10 faceplate finishes

Notes

  • Handing is determined as viewed from outside the door
  • The Horizon and Europa plates are only 1-7/8 inches wide and will not cover the 2-1/8 inch cross bore used on Pella and other doors with larger holes
  • Lock handing can be reversed - see installation video

Priced and sold each.

Fill out our MPL form or call us to ensure accurate purchasing and correct fit.

Frequently Asked Questions

What hardware is compatible with this multipoint lock?

The standard 2-1/8 inch cross bore works with Pinnacle, Eclipse, and Grip hardware. The optional 1-11/16 inch cross bore accommodates Europa, Horizon, and Emtek hardware.

Can I reverse the handing on this lock?

Yes, this lock is reversible. View the installation video for instructions on how to change the handing.

Does this lock include a cylinder?

No, the cylinder is not included. This lock requires an American cylinder with a flat tailpiece.
