Winkhaus One Motion Lock (OML) – 45mm Backset, 92mm PZ, Key Above Handle (Discontinued)

Winkhaus One Motion Lock (OML) – 45mm Backset, 92mm PZ, Key Above Handle (Discontinued)

SKU: 499116299

Sold out
$0.00 - $0.00
$0.00
$0.00 - $0.00
$0.00
  • Status: Discontinued – No longer available
  • PZ: 92mm (3-5/8")
  • Backset: 45mm (1-3/4")
  • Key Position: Key above handle
  • Faceplate Width: 13/16" (20mm)
  • Overall Length: 76-1/4" (1936.8mm)
  • Handle Height: 36" (914.4mm)
  • Hook Projection: 7/8" (22.2mm)
  • Top Hook Position: 27-5/8" (701.7mm) from handle
  • Bottom Hook Position: 27" (685.8mm) from handle
  • Locking Devices: Hook type locks
  • Compatible Door Brands: Manco, Milgard Fiberglass Door, and others
  • One Motion Lock (OML) design – automatic retraction of hooks and deadbolt when handle is depressed
This product has been discontinued and is no longer available
  • American Express
  • Apple Pay
  • Diners Club
  • Discover
  • Google Pay
  • Mastercard
  • PayPal
  • Shop Pay
  • Visa
Not sure this is the right part?
Before you order, if you'd like confidence this is the right part for your job, please fill out our multipoint lock identifier form or call us at (816) 221-6543.
*We have a fully-staffed customer support team happy to help!

Winkhaus OML Key Above – 45/92 (499116299)

This Winkhaus One Motion Lock (OML) multipoint lock system has been discontinued and is no longer available for purchase. The OML design featured automatic retraction of hooks and deadbolt when the handle was depressed, providing smooth single-motion operation for entry doors.

This lock was designed for door panels measuring 76-1/4 inches tall and was compatible with Manco, Milgard Fiberglass Door, and other door brands. The key cylinder was positioned above the handle.

Technical Information

  • PZ (Handle to Cylinder Center): 92mm (3-5/8 inches)
  • Backset: 45mm (1-3/4 inches)
  • Faceplate Width: 20mm (13/16 inches)
  • Overall Length: 76-1/4 inches (1936.8mm)
  • Handle Height: 36 inches (914.4mm)
  • Hook Projection: 7/8 inches (22.2mm)
  • Top Hook Position: 27-5/8 inches from handle center
  • Bottom Hook Position: 27 inches from handle center
  • Spring Latch: 13/16 inches above center of handle
  • Deadbolt: 3-1/16 inches to top of deadbolt latch
  • Faceplate Support Pins: Project 3/8 inches or 1/2 inches with faceplate

Notes

  • Door measurements may vary from specifications listed
  • Latch handing can be reversed – see Winkhaus multipoint lock handing guide
  • Compatible with Manco, Milgard Fiberglass Door, and other door brands

This product has been discontinued.

Fill out our MPL form or call us to ensure accurate purchasing and correct fit.

Frequently Asked Questions

What does One Motion Lock (OML) mean?

The Winkhaus One Motion Lock design automatically retracts all hooks and the deadbolt when the handle is depressed, allowing you to open the door with a single motion.

Can the latch handing be reversed on this lock?

Yes, Winkhaus multipoint locks can be rehanded. Refer to the handing guide for instructions on how to reverse the latch slope.

Is this lock still available?

No, this Winkhaus One Motion Lock has been discontinued and is no longer available for purchase. Please contact us for potential alternatives.
