Marvin Active Vertical Rod Lock Body – 92mm PZ (Discontinued)

Marvin Active Vertical Rod Lock Body – 92mm PZ (Discontinued)

SKU: 10148030

  • Status: Discontinued – no longer available for purchase
  • Type: Active door concealed vertical rod multipoint lock body (rods not included)
  • PZ (Handle Spacing): 92mm (3-5/8")
  • Handle Height: Standard 36" (914.4mm)
  • Lock Body Length: 6" (152.4mm)
  • Lock Body Depth: 3" (76.2mm)
  • Faceplate Length: 8-3/8" (212.7mm)
  • Faceplate Width: 3/4" (19mm)
  • Faceplate Style: Radius / Rounded Corners
  • Features: Spring latch and deadbolt
  • Application: Single or double French doors (active door only)
  • Installation Screws: 7 screws, 1/2" (12.7mm)
This product has been discontinued and is no longer available
Not sure this is the right part?
Before you order, if you'd like confidence this is the right part for your job, please fill out our multipoint lock identifier form or call us at (816) 221-6543.
*We have a fully-staffed customer support team happy to help!

Marvin Active Vertical Rod Lock Body – 92mm PZ (10148030)

This lock has been discontinued and is no longer available for purchase.

This Marvin Active Vertical Rod Lock Body is a concealed rod multipoint lock designed for active doors in single or double French door configurations. The lock body features a spring latch and deadbolt mechanism, with vertical locking rods that screw into the mortise lock body. Please note that the locking rods are not included with this lock body.

This lock is specifically designed for active doors only. The passive door requires a different lock. The faceplate features radius (rounded) corners and measures 8-3/8 inches in length by 3/4 inch in width.

Technical Information

  • PZ (Handle Spacing): 92mm (3-5/8 inches)
  • Handle Height: Standard 36 inches (914.4mm)
  • Lock Body Length: 6 inches (152.4mm)
  • Lock Body Depth: 3 inches (76.2mm)
  • Faceplate Length: 8-3/8 inches (212.7mm)
  • Faceplate Width: 3/4 inch (19mm)
  • Faceplate Style: Radius / Rounded Corners
  • Installation Screws: 7 screws, 1/2 inch (12.7mm)

Notes

Since this lock is discontinued, several replacement options are available:

For Single Doors (best suited for trim carpenters):

  • Switch to a single point lock with a slightly larger body (40160). You will need a new strike plate (395035) and a new lock faceplate (395040).
  • Route door edge and install face mount shootbolt version multipoint lock (Truth Sentry, key above). Will need new strike plates.
  • Replace door(s).

For Double Doors (best suited for trim carpenters):

  • Switch to a single point system, replacing both active and passive locks. Add flush bolts to passive door in place of rod version. Will need new strike plates, faceplates, and flush bolts.
  • Replace active and passive locks with shootbolt version (route face mount on door edge).

For more information, contact: Rory@allaboutdoors.com

Related Parts

  • 40160 - Single Point Lock (replacement option)
  • 395035 - Strike Plate (for single point conversion)
  • 395040 - Lock Faceplate (for single point conversion)

Fill out our MPL form or call us to ensure accurate purchasing and correct fit.

Frequently Asked Questions

Why is this lock discontinued and what are my options?

This Marvin concealed rod multipoint lock is no longer manufactured. Replacement options include switching to a single point lock system (part 40160) or installing a face mount shootbolt version multipoint lock.

What is the difference between active and passive door locks?

The active door is the primary door you use to enter and exit, which operates the locking mechanism. The passive door remains stationary and requires a different lock designed for that application.

Are the vertical locking rods included with this lock body?

No, this is the lock body only. The vertical locking rods that screw into the mortise lock body are sold separately.
