HOPPE Tongue Shootbolt Multipoint Locks

HOPPE HLS9000 Tongue and Shootbolt Multipoint Lock Systems

HOPPE's tongue and shootbolt configuration represents one of the most versatile multipoint lock designs in the European hardware market. These locks feature a primary tongue bolt that engages at a fixed position 24.41 inches below the lever, paired with shootbolts that extend into the door frame at top and bottom for three-point security. MPLocks carries the complete range of HOPPE HLS9000 tongue/shootbolt assemblies, including bottom gear units, top extensions, and complete lock packages to match your door specifications.

Precision Engineering for Reliable Operation

HOPPE tongue and shootbolt locks are manufactured to exacting European standards, ensuring smooth operation and long-term durability. The tongue mechanism provides primary latching while the shootbolts add structural security against forced entry. Available in both 16mm (5/8 inch) and 20mm (3/4 inch) faceplate widths, these locks accommodate various door stile dimensions commonly found in wood, fiberglass, and aluminum-clad entry doors from manufacturers who use Fuhr-style hardware.

Multiple Backset and Extension Options

Finding the right replacement requires matching your existing lock's backset measurement—the distance from the faceplate to the center of the lever spindle. These HOPPE locks are available in 35mm (1-3/8 inch), 45mm (1-3/4 inch), 60mm (2-3/8 inch), and 70mm (2-3/4 inch) backsets. Top extension locations vary across seven possible positions measured from the lever, allowing you to match virtually any existing Hoppe or Fuhr multipoint configuration.

• HOPPE Tongue Multipoint Lock Systems
• HOPPE Shootbolt Multipoint Lock Hardware
• HOPPE HLS9000 Handle Sets and Cylinders

Measuring for Your Replacement Lock

Accurate measurements are essential when ordering a tongue and shootbolt multipoint lock. Start by measuring your faceplate width, then determine the backset by measuring from the edge of the faceplate to the center of the lever hole. Next, measure the distance from the lever centerline to the top extension's locking point—this is critical since HOPPE offers seven different top tongue positions. The bottom tongue position is standardized at 24.41 inches (620mm) from the lever on all units, but always verify this matches your existing strike locations.

Need help confirming which tongue and shootbolt lock fits your door? Our team is available at (816) 221-6543 to walk you through the measurement process and verify compatibility. You can also use our free Multipoint Lock Identifier to submit your lock details for expert review and receive personalized replacement recommendations.
