AGB Unitop 3-Point Multipoint Lock with Shootbolts – 92mm PZ, Variable Backset

SKU:

$275.00 - $315.00

$275.00

$275.00 - $315.00

$275.00

PZ: 92mm (3-5/8")
Backset: Choose from 35mm, 40mm, 45mm, 50mm, or 55mm
Faceplate Width: 5/8" (16mm)
Door Height Range: 70-7/8" to 82-5/8" (1800-2100mm)
Handle Height: 41-5/16" (1050mm), adjustable from 37-5/16" to 45-5/16"
Locking Points: 3-point system with deadbolt and upper/lower shootbolts
Shootbolt Throw: 9/16" (15mm)
Cylinder Type: Euro Profile (not included), keyed below handle
Spindle Diameter: 5/16" (8mm)
Overall Faceplate Length: 75-5/8" (1920mm) without top shootbolt
Activation: Lift handle to engage all locking points
Handing: Reversible latch
Lead Time: Non-stock item, 10-14 days

Quantity

Not sure this is the right part?

Before you order, if you'd like confidence this is the right part for your job, please fill out our multipoint lock identifier form or call us at (816) 221-6543.

*We have a fully-staffed customer support team happy to help!

Product Details

AGB Unitop 3-Point Lock Kit (49915000-KIT)

The AGB Unitop is a versatile 3-point multipoint lock system featuring a deadbolt with upper and lower shootbolts. This complete kit is designed for doors ranging from 70-7/8 inches to 82-5/8 inches (1800-2100mm) in height and can be cut to length for various handle and door height configurations.

The lock is activated by lifting the handle, which simultaneously extends the deadbolt while the bottom shootbolt moves down and the top shootbolt moves up. Turn the key or thumb turn to secure the door in the locked position. The latch handing can be reversed by removing the screw in the latch, rotating it, and reinstalling.

Stamped With

455, 92, 120, 180, 1800-2100 (on faceplate)

Technical Information

Brand: AGB
Model: Unitop
PZ (Handle to Cylinder Center): 92mm (3-5/8 inches)
Backset Options: 35mm, 40mm, 45mm, 50mm, or 55mm
Faceplate Width: 16mm (5/8 inch)
Overall Faceplate Length: 1920mm (75-5/8 inches) without top shootbolt
Handle Height: 1050mm (41-5/16 inches) standard, adjustable from 948mm to 1150mm
Spindle Diameter: 8mm (5/16 inch)
Shootbolt Throw: 15mm (9/16 inch)
Cylinder Type: Euro Profile (not included)
Key Position: Below lever handle

Notes

This multipoint lock may require cutting the top and bottom faceplate with a hacksaw and attaching shootbolt tips
For doors greater than 82-5/8 inches (2100mm), one or more extensions will be required
For shorter doors, cut the lock faceplate up to 11-13/16 inches (300mm)
To change handle height, you will need the 120mm bottom shootbolt (A40486.00.02)
Minimum handle height: 37-5/16 inches (948mm) by cutting lock face
Maximum handle height: 45-5/16 inches (1150mm) by cutting lock face

Related Parts

A41455.xx.09.853 - Main Assembly (xx = backset)
A40486.00.01 - 180mm Upper Shootbolt
A40486.00.02 - 120mm Bottom Shootbolt (for handle height adjustment)

Kit includes main assembly, 180mm upper shootbolt, and ten 1-3/8 inch (35mm) stainless steel screws. Non-stock item with normal lead time of 10-14 days.

Fill out our MPL form or call us to ensure accurate purchasing and correct fit.

Frequently Asked Questions

How do I activate the locking points on this AGB Unitop lock?

Lift the handle to engage all locking points simultaneously. The deadbolt extends while the bottom shootbolt moves down and the top shootbolt moves up. Turn the key or thumb turn to secure in the locked position.

Can I reverse the handing on this multipoint lock?

Yes, the latch handing can be reversed. Remove the screw in the latch, rotate the latch, and reinstall the screw.

What if my door is taller than 82-5/8 inches?

For doors greater than 82-5/8 inches (2100mm), you will need one or more extensions. For shorter doors, the lock faceplate can be cut up to 11-13/16 inches (300mm).
