Marvin Integrity Passive Handleset – Right Hand Inswing

Marvin Integrity Passive Handleset – Right Hand Inswing

SKU

$146.72 - $475.08
$146.72
$146.72 - $475.08
$146.72
  • Function: Passive secondary door handle (no keyway)
  • Handing: Right Hand Inswing (RHIS) – can be changed with removable clip
  • Screw Hole Spacing: 7-5/8" (193.7mm)
  • Escutcheon Plate Width: 1.35" (34.3mm)
  • Escutcheon Plate Length: 9.25" (235mm)
  • Complete handleset includes interior and exterior components
  • Compatible with Integrity doors by Marvin
  • Sold as a complete handleset
Visa Mastercard American Express Discover
Estimated Delivery
Between December 13 and December 17
*Delivery dates are estimates and may vary based on availability and shipping method

Marvin Integrity Passive Handleset – RHIS (9340004)

This Marvin Integrity passive handleset is designed for secondary doors in multipoint door systems. As a passive handle, it does not include a keyway and is intended for the non-locking leaf of a double door configuration.

The handleset is sold as a complete unit, combining both interior and exterior components. If you prefer a split finish with different colors on the inside and outside, please contact our office for assistance.

Handing is determined from the outside of the door. If you are standing outside and the door swings into the room with hinges on the right, this is a Right Hand Inswing (RHIS) configuration. The lever handing can be changed using a removable clip, allowing for field adjustment if needed.

Technical Information

  • Function: Passive Secondary Door
  • Keyway: None
  • Screw Hole Spacing: 7-5/8 inches (193.7mm)
  • Escutcheon Plate Width: 1.35 inches (34.3mm)
  • Escutcheon Plate Length: 9.25 inches (235mm)
  • Handing: Right Hand Inswing (RHIS)

Notes

This handleset is available in multiple finishes. Use the following part number combinations to order by finish:

  • PVD Brass (BS): 11868048 Ext + 11869128 Int (Old: 11869232)
  • White (WH): 11868047 Ext + 11869127 Int (Old: 11869234)
  • Almond Frost (AF): 11868046 Ext + 11869126 Int (Old: 11869236)
  • PVD Satin Nickel (SN): 11868049 Ext + 11869129 Int (Old: 11869238)
  • PVD Oil Rubbed Bronze (ORBZ): 11868050 Ext + 11869130 Int (Old: 11869240)

Related Parts

  • 11868048 - Exterior Component (PVD Brass)
  • 11869128 - Interior Component (PVD Brass)
  • 11868047 - Exterior Component (White)
  • 11869127 - Interior Component (White)
  • 11868046 - Exterior Component (Almond Frost)
  • 11869126 - Interior Component (Almond Frost)
  • 11868049 - Exterior Component (PVD Satin Nickel)
  • 11869129 - Interior Component (PVD Satin Nickel)
  • 11868050 - Exterior Component (PVD Oil Rubbed Bronze)
  • 11869130 - Interior Component (PVD Oil Rubbed Bronze)

Sold as a complete handleset.

Fill out our MPL form or call us to ensure accurate purchasing and correct fit.

Frequently Asked Questions

How do I determine the handing for my door?

Stand outside the door. If the door swings into the room and the hinges are on the right side, it is a Right Hand Inswing (RHIS). If hinges are on the left, it is a Left Hand Inswing (LHIS).

Can I change the handing on this handleset?

Yes, the lever handing can be changed. The levers are held on with a removable clip that allows for field adjustment.

What is a passive handleset used for?

A passive handleset is used on the secondary (non-locking) leaf of a double door configuration. It does not include a keyway or locking mechanism.
