Hoppe HLS9000 Bottom Gear – Two Roller, 45mm Backset, Manual Locking

Hoppe HLS9000 Bottom Gear – Two Roller, 45mm Backset, Manual Locking

SKU 8778223

$142.77 - $142.77
$142.77
$142.77 - $142.77
$142.77
  • Backset: 1-3/4" (45mm)
  • Faceplate Width: 5/8" (16mm)
  • Handle Height: 36" (914mm)
  • Deadbolt Throw: 1" (25.4mm)
  • Bottom Roller Position: 29.53" (750mm) in down position
  • Maximum Cutoff: 2.36" (60mm)
  • Number of Screws: 5
  • Two roller version with manual locking
  • HLS9000 series bottom gear
Visa Mastercard American Express Discover
Estimated Delivery
Between December 11 and December 15
*Delivery dates are estimates and may vary based on availability and shipping method

Hoppe HLS9000 Bottom Gear – Two Roller (8778223)

This Hoppe bottom gear is designed for HLS9000 series multipoint lock systems. It features a two roller configuration with manual locking operation, providing reliable security for hinged doors.

The bottom gear has a 1-3/4 inch (45mm) backset and a 5/8 inch (16mm) faceplate width. The handle height measures 36 inches (914mm), with the bottom roller positioned at 29.53 inches (750mm) in the down position. The deadbolt throw is 1 inch (25.4mm), and the maximum cutoff is 2.36 inches (60mm). Five screws are included for installation.

Technical Information

  • Backset: 1-3/4 inches (45mm)
  • Faceplate Width: 5/8 inch (16mm)
  • Handle Height: 36 inches (914mm)
  • Bottom Roller Position: 29.53 inches (750mm) in down position
  • Deadbolt Throw: 1 inch (25.4mm)
  • Maximum Cutoff: 2.36 inches (60mm)
  • Number of Screws: 5
  • Locking Type: Manual
  • Roller Configuration: Two roller version

Notes

  • Handing can be changed or reversed if needed
  • Compatible with HLS9000 series multipoint lock systems

Fill out our MPL form or call us to ensure accurate purchasing and correct fit.

Frequently Asked Questions

Can I change the handing on this Hoppe bottom gear?

Yes, Hoppe multipoint locks can be rehanded. Refer to the manufacturer's instructions for changing or reversing the handing of the lock.

What is the maximum cutoff for this bottom gear?

The maximum cutoff is 2.36 inches (60mm), which determines how much material can be removed from the bottom of the gear during installation.

How do I know if this is the right bottom gear for my door?

Verify your backset measurement (1-3/4 inches or 45mm), handle height (36 inches), and confirm you have an HLS9000 series multipoint lock system.
