GU Secury Automatic Multipoint Lock for 6' 8" Doors – 55mm Backset, 92mm PZ

GU Secury Automatic Multipoint Lock for 6' 8" Doors – 55mm Backset, 92mm PZ

SKU 6-40526-05-R-SS

$507.88 - $507.88
$507.88
$507.88 - $507.88
$507.88
  • PZ (Cylinder to Spindle): 3-5/8" (92mm)
  • Backset: 2-3/16" (55mm)
  • Faceplate Width: 5/8" (16mm)
  • Handle Height: 41-5/16" (1050mm)
  • Deadbolt Throw: 3/4" (20mm) croppable
  • Spindle Hub: 5/16" (8mm)
  • Door Size: Fits 6' 8" doors
  • Material: 304 Stainless Steel
  • Cylinder Type: European Profile cylinder, key operated
  • Gear driven automatic multipoint lock – latches extend automatically when door closes
  • No lever handle needed – operates with key or thumb turn only
  • Compatible with optional push/pull bars and accessories
Visa Mastercard American Express Discover
Estimated Delivery
Between December 13 and December 17
*Delivery dates are estimates and may vary based on availability and shipping method

GU Secury Automatic Multipoint Lock – 55/92, 6' 8" Door (6-40526-05-R-SS)

The GU Secury Automatic is a gear-driven European Profile cylinder multipoint lock designed for modern, clean-looking doors. This lock operates without lever handles – simply use your key from the exterior or thumb turn from the interior to lock and unlock the door.

What makes the Secury Automatic stand out is its automatic latching system. Every time the door closes, the top and bottom latches extend 3/4 inch (20mm) to secure the door in the locked position without any additional handle lifting. This keeps the door in proper alignment and eliminates the need for a second operation to engage the multipoints.

To open the door, turn the key or thumb turn 180 degrees to retract the deadbolt, then an additional 180 degrees to retract the latches. The lock is constructed from durable 304 stainless steel for long-lasting performance.

Technical Information

  • PZ (Cylinder to Spindle): 3-5/8 inches (92mm)
  • Backset: 2-3/16 inches (55mm)
  • Faceplate Width: 5/8 inch (16mm)
  • Handle Height: 41-5/16 inches (1050mm)
  • Deadbolt Throw: 3/4 inch (20mm) croppable
  • Spindle Hub: 5/16 inch (8mm)
  • Door Size: Fits 6 feet 8 inch doors
  • Material: 304 Stainless Steel
  • Cylinder Type: European Profile, key operated

Notes

  • No lever handles required – operates with key or thumb turn only
  • Optional push/pull bars and accessories available separately

Related Parts

  • K-C8153-01-0-0 - Set Motor Secury Automatic Universal
  • K-C5560-20-4-BLPC - GU Secure Connect 200 Lock
  • K-C0340-08-P-8B - Double Pull Bars, Round, 31-1/2 inches (800mm)
  • K-C0340-12-P-8B - Double Pull Bars, Round, 47-1/4 inches (1200mm)
  • K-C0340-18-P-8B - Double Pull Bars, Round, 70-7/8 inches (1800mm)
  • K-C0345-08-P-8B - Double Pull Bars, Round 45° Offset, 800mm
  • K-C0345-12-P-8B - Double Pull Bars, Round 45° Offset, 1200mm
  • K-C0345-18-P-8B - Double Pull Bars, Round 45° Offset, 1800mm
  • K-C0350-12-P-8B - Double Pull Bars, Rectangular, 1200mm
  • 6-C0531-00-0-8B - Interior Caps for Pull Bars
  • K-C0960-00-0-8B - Support Plates for Pull Bars (4 pack)

Fill out our MPL form or call us to ensure accurate purchasing and correct fit.

Frequently Asked Questions

Do I need lever handles with the GU Secury Automatic lock?

No, this lock operates without lever handles. You use a key from the exterior or a thumb turn from the interior to lock and unlock the door.

How does the automatic latching feature work?

When the door closes, the top and bottom latches automatically extend 3/4 inch to secure the door in the locked position without lifting a handle.

What type of cylinder does this lock use?

This lock uses a European Profile cylinder that is key operated from the exterior.
