GU Europa R2 Multipoint Lock Gear – 35mm Backset, 92mm PZ, Silver Ferguard

SKU 6-33632-01-0-FG

$220.25 - $220.25

$220.25

$220.25 - $220.25

$220.25

PZ (Handle to Cylinder): 3-5/8" (92mm)
Backset: 1-3/8" (35mm)
Faceplate Width: 5/8" (16mm)
Faceplate Finish: Silver Ferguard
Handle Position: Key below handle (Europa)
Handle Height: Typically 35" (889mm)
Top Roller Position: 11-1/16" (280mm)
Bottom Roller Position: 15-3/8" (390mm)
Rollers Center-to-Center: 26.4" (670.5mm)
Spindle Size: 8mm square
Cylinder Type: American cylinder system with 90° turn
Function: Shootbolt version, locks vertically at top and bottom
Non-handed, latch easily reversible
Does not include top or bottom shootbolts
Sold individually

Estimated Delivery

Between December 13 and December 17

*Delivery dates are estimates and may vary based on availability and shipping method

Product Details

GU Europa R2 Multipoint Lock – 35/92, Silver (6-33632-01-0-FG)

The GU Europa R2 multipoint door lock gear is a 5-point locking system designed for secure residential and commercial door applications. This lock body features two adjustable rolling pins, a deadbolt, and a latch, with provisions for top and bottom shootbolts that lock vertically at the top and bottom of the door panel.

This lock uses an American cylinder system with a 90-degree turn of key or thumbturn, compatible with Schlage "C" keyway systems. The non-handed design allows the latch to be easily reversed for left or right-hand door installations. Heavy-duty mortise construction with a reinforced lever return spring system ensures long-lasting durability.

The Europa R2 is typically used with a 35-inch handle height. Notably, the Europa R2 and Europa Inactive are the only locks in the GU lineup that can achieve a 39-inch handle height with shootbolts at the bottom. The R2 cams can be removed, but the slot in the faceplate where they travel will remain visible as there is no cover available for this slot.

Technical Information

Series: Europa Door Lock Gear
PZ (Handle to Cylinder): 3-5/8 inches (92mm)
Backset: 1-3/8 inches (35mm)
Faceplate Width: 5/8 inches (16mm)
Faceplate Finish: Silver Ferguard
Top Roller Position: 11-1/16 inches (280mm)
Bottom Roller Position: 15-3/8 inches (390mm)
Rollers Center-to-Center: 26.4 inches (670.5mm)
Spindle Size: 8mm square
Cylinder Type: American cylinder system (90° turn)
Handle Height: 35 inches (889mm) typical
Locking Points: 5-point system (two adjustable rolling pins, deadbolt, latch, plus top and bottom shootbolts)

Notes

Does not include top or bottom shootbolts – sold separately
Non-handed design with easily reversible latch
Extensions with additional rolling pins available for taller doors
Same hardware groove detail throughout the GU door lock program (router bits available)
The R2 cams can be removed but the faceplate slot will remain visible with no cover available

Related Parts

G-16790-05-0-1 – Extension, 500mm length, Silver
G-20416-00-0-1 – Top Shootbolt, Reversing Gear, Silver
G-20415-00-01 – Bottom Shootbolt, Silver
9-34442-00-0-0 – Brass Sleeve / Socket Strike

Sold individually.

Fill out our MPL form or call us to ensure accurate purchasing and correct fit.

Frequently Asked Questions

Does this lock include the shootbolts?

No, the top and bottom shootbolts are sold separately. Related part numbers are G-20416-00-0-1 for the top shootbolt and G-20415-00-01 for the bottom shootbolt.

What cylinder type does this lock use?

This lock uses an American cylinder system with a 90-degree turn of key or thumbturn, compatible with Schlage "C" keyway systems.

Can this lock be used on left or right-hand doors?

Yes, this lock features a non-handed design with an easily reversible latch, making it suitable for both left and right-hand door installations.
