Amesbury 400 Series Inactive Handleset for Multipoint Doors – 92mm PZ, Oil Rubbed Bronze

SKU: 395114-ORB

$156.38 - $156.38

$156.38

$156.38 - $156.38

$156.38

PZ: 92mm (3-5/8")
Door Thickness: 1-3/4" (44.5mm)
Escutcheon Plate: 1.80" x 9.52" (45.7mm x 241.8mm) - Style "B" with rounded radius top
Screw Hole Spacing: 7.87" (200mm)
Spindle: 5/16" (8mm) square
Finish: Oil Rubbed Bronze
Base Material: Zinc
Function: Inactive/Passive - levers operate shootbolts, no key or thumbturn
Handing: Handed, but handles can be removed and reattached to change orientation
Spring loaded cassette for added lever action
Uses snap ring to secure handles (no set screws)
Priced and sold each

Not sure this is the right part?

Before you order, if you'd like confidence this is the right part for your job, please fill out our multipoint lock identifier form or call us at (816) 221-6543.

*We have a fully-staffed customer support team happy to help!

Product Details

Amesbury 400 Series Inactive Handleset – ORB (395114-ORB)

This Amesbury 400 Series inactive handleset is designed for secondary passive doors equipped with multipoint locking systems. The curved lever design with rounded radius top escutcheon plate provides an elegant appearance while delivering reliable shootbolt operation on inactive doors.

This passage-type hardware allows the levers to move and operate the shootbolts without requiring a key cylinder or interior thumbturn. It's the ideal solution for the passive leaf of double French doors or any secondary door that needs shootbolt control without keyed access.

The handleset features a spring-loaded cassette mechanism for smooth lever action and uses a snap ring retention system rather than set screws to secure the handles to the escutcheon plate. While the hardware is handed, the handles can be removed and reattached to accommodate either left or right hand door configurations.

Technical Information

PZ (Cylinder to Handle Spacing): 92mm (3-5/8 inches)
Door Thickness: 1-3/4 inches (44.5mm)
Escutcheon Plate Dimensions: 1.80 inches x 9.52 inches (45.7mm x 241.8mm)
Escutcheon Plate Style: "B" with rounded radius top
Screw Hole Spacing: 7.87 inches (200mm)
Installation Screws: M5 x 58mm
Spindle Diameter: 5/16 inch (8mm) square
Base Material: Zinc
Finish: Oil Rubbed Bronze

Notes

Non-stock handle sets have a 90 day lead time - call for availability before ordering
Amesbury 400 Series curved lever design
Handles use snap ring retention (no set screws)
Can be rehanded by removing and reattaching handles

Replaces / Replaced by

Replaces Integrity by Marvin Cambridge series multipoint lock trim
Replaces Milgard multipoint lock trim
Replaces other American version multipoint locks that do not require an inside thumbturn

Priced and sold each.

Fill out our MPL form or call us to ensure accurate purchasing and correct fit.

Frequently Asked Questions

What is the difference between Active, Inactive, and Dummy handlesets?

Active handlesets include a key cylinder and interior thumbturn for locking. Inactive/Passive handlesets (like this one) have levers that operate shootbolts but no key or thumbturn. Dummy handlesets have fixed, non-moving levers for decorative purposes only.

Can I change the handing on this handleset?

Yes, the handles can be removed and reattached to accommodate either left or right hand door configurations. The handles use a snap ring retention system rather than set screws.

What does PZ measurement mean?

PZ refers to the distance from the center of the handle spindle to the center of the cylinder bore hole. This handleset has a 92mm PZ spacing, which is a common European standard measurement.
