Ashland Active Multipoint Lock – 70mm Backset, Radius Faceplate

SKU: 4991635

$180.68 - $180.68

$180.68

$180.68 - $180.68

$180.68

Backset: 2-3/4" (70mm) with riveted 3/8" spacer
Faceplate Width: 1-1/16" (27mm)
Faceplate Length: 15-15/16" (405mm)
Faceplate Corners: Radius
Rod Connection Thread: 1/4-20
Markings: Patent NO. 6,209,931
Active multipoint lock with concealed shootbolt rods at top and bottom
Used by Peachtree and other manufacturers
Does not fit Marvin doors
Lock body only – rods not included
Faceplate is riveted to lock case
Can be rehanded in the field
Sold individually

Not sure this is the right part?

Before you order, if you'd like confidence this is the right part for your job, please fill out our multipoint lock identifier form or call us at (816) 221-6543.

*We have a fully-staffed customer support team happy to help!

Product Details

Ashland Active Multipoint Lock – 70mm Backset, Radius (4991635)

This Ashland active multipoint lock features concealed shootbolt rods that extend at the top and bottom of the door panel for secure multi-point locking. The lock body includes a pre-attached faceplate with radius ends and is designed for doors requiring a 2-3/4 inch (70mm) backset with a riveted 3/8 inch spacer.

This lock is used by several door manufacturers including Peachtree. Please note that this lock does not fit Marvin doors. The faceplate is permanently riveted to the lock case.

Stamped With

Patent NO. 6,209,931

Technical Information

Backset: 2-3/4 inches (70mm) with riveted 3/8 inch spacer
Faceplate Width: 1-1/16 inches (27mm)
Faceplate Length: 15-15/16 inches (405mm)
Faceplate Corners: Radius
Rod Connection Thread: 1/4-20

Notes

Does not include rods – this is the gear box only
Faceplates are available with either square or radius corners
Does not fit Marvin doors

Operation

Lift handle to extend concealed rods
Turn key or thumbturn to extend deadbolt

How to Change Handing

Insert screwdriver into slot behind latch
Pull down on handing release – latch pops out
Rotate latch and push back into lock case
Always check function of lock before closing door

Installation Tips

The rods have a guide bracket at the top and bottom of the door that needs to be removed to access the rods. The rods feature a hex shape that allows an extended socket to fit. If you remove the top bracket and top rod, the lock body may sometimes be removed with the bottom rod still attached.

Related Parts

Strybuc Industries 56-127 (similar or same part)

Sold individually.

Fill out our MPL form or call us to ensure accurate purchasing and correct fit.

Frequently Asked Questions

Does this lock include the shootbolt rods?

No, this is the lock body (gear box) only. The concealed shootbolt rods are sold separately.

Can I change the handing on this lock?

Yes, insert a screwdriver into the slot behind the latch, pull down on the handing release until the latch pops out, rotate the latch, and push it back into the lock case.

Will this lock fit my Marvin door?

No, this lock does not fit Marvin doors. It is designed for Peachtree and other compatible door brands.
